M.E.L.B.A. Multi Element Bolometer Array
Bolometer-Arrays with highest resolution are the key-diagnostic in
nuclear Plasma-reactors of tomorrow.
Controlled nuclear fusion requires miniaturized, low-noise
metal-layer bolometer-arrays for the broad band measurements of
radiation emmited by the plasma.
M.E.L.B.A.-Technology offers the most advanced versions of
metal-layer bolometer-arrays. Unmatched sensitivity with
unprecedented signal to noise ratio, perfect in situ calibration and
unparalleled long term stabilility with a range of operation up to
400°C and marginal temperature drift.
M.E.L.B.A.-Technology is black in a wide spectral range from IR- to Soft-X-field.
M.E.L.B.A.-Technology is robust against high magnetical fields, ultra high
vacuum and intensive nuclear radiation.
M.E.L.B.A.-Technology provides integrated Wheatstone-bridge with
remarkable symetry. A prerequisite for optimal suppression of
electromagnetical, thermal and nuclear interfering signals.
M.E.L.B.A.-Technology is the result of modern fabrication processes
combined with a radical redesign of the bolometer layout.
M.E.L.B.A.-Technology means Bolometer-Arrays with smallest footprint.
M.E.L.B.A.-Technology allows fine tuning thermal properties exactly to
M.E.L.B.A.-Technology is a consistent enhancement of the well-known
metal-layer-bolometers already in use in plasma-reactors for over 20
M.E.L.B.A.-Technology is faster, more robust, more sensitive, smaller
and more versatile, than any other hitherto known bolometer-type.
M.E.L.B.A.-Technology offers miniaturized bolometer-cameras with up to
30 integrated channels on one foil with almost no property variations from channel to channel.
M.E.L.B.A.-Technology has and will be constanly improved
for a wide range of applications hitherto unimaginable for
M.E.L.B.A.-Technology is carried by their
inventors (K.F.Mast and P.Betzler).
Our goal is to provide best performance bolometers based on 20 years
Constantly improving the technologie of a 20 year success story.
Bolometer-constant τ = 100ms
customizable from 20 to 500ms
Temperature resistant up to 400°C
- High symmetry of wheatstone
resistance bridge ΔR ≤ 1%
- minimal offset
- minimal noise
- negligible crosstalk
- robust to nuclear radiation
- easiest installation, plug mountable.
- extremely ruggedized
- minimal foot-print.
|absorber ||Gold thickness 1..15µm |
|heat flow layer ||Gold 0,02..0,08µm |
|Resistors ||platinum |
|carrier foil ||Capton®, glimmer, ceramics |
| ||8..15µm |
|Bridge voltage ||20VAC |
|resistance R ||> 1kΩ |
latest technologie: feedback bolometer mesuring absorbed radiation instantaneous.
offset free measurement on the lowest noise level up to 130db signal noise ratio.
calibration in situ offering highest quality measurement in variant
ambient temperature ΔT ≥ 100°.
Customized Bolometer-Cameras for as low as 4000,-- € per channel.
